    • Reelworks 820 c/w R2 15m x 3/8" 276bar

      77012

      £436.47

      Features:
      Heavy duty steel construction for a long life in both the industrial and automotive sectors
      Reel drum has been coated, with a durable blue powder coated finish
      Dual pedestal base
      Double supported 1.3/8" axle
      Full flow shaft and swivel assembly, structurally reinforced
      Multi position roller guide assembly
      Latching of the hose at any required length up to 15m (50')
      Four way roller guides to reduce hose wear
      Floor, wall or ceiling mount
      Internally mounted fully enclosed and lubricated spring assembly
      12 month manufacturers warranty (excluding hose and seals)
      Alt Code: C820-350H

      The 820 Series are high performance spring rewind hose reels, constructed in a black powder-coated steel. Twin supports make this reel ideal for high-pressure jet washing either static or on mobile vehicles.

      Hose Capacity 15 mtr (50')
      Hose ID 3/8” / 10mm
      Max Working Pressure 276 bar / 4000PSI
      Working Temperature 100°C
      Inlet / Outlet 3/8” BSPF / 3/8” BSPM
      Hose Type High pressure jet wash
      Reel Dimensions W: 23cm x H: 52cm x D: 54cm
      Approx Weight 27kg
